My Multi-Server Homelab: The Full Architecture

Three VPSes. 30+ containers. One Tailscale mesh holding it all together. Here's every service, every connection, and how they talk to each other.

The Setup

Main VPS (Hetzner) - Reverse proxy, DNS, auth, media, mail, everything else
Transmission VPS (Hetzner) - Torrenting through Mullvad VPN
OCI VPS (Oracle Cloud) - Media transcoding

All three servers are connected via Tailscale (100.x.x.x addresses). The Main VPS runs Traefik as the single public entry point for all web traffic across all servers. Authentik handles SSO for protected services. A Hetzner Storage Box is mounted on all servers for shared media storage.

Network Overview

How traffic flows from the internet through Traefik to services across all three servers.

High-level network topology - all web traffic enters through Traefik on the Main VPS

Main VPS - All Services Behind Traefik

Every service on the main VPS is exposed through Traefik with automatic Let's Encrypt certificates.

Main VPS service map - all subdomains are \*.kanishksachdev.com

Media Pipeline

The fully automated media acquisition and processing pipeline.

Request to stream - Jellyseerr to Jellyfin, with VPN-tunneled downloads and distributed transcoding

Authentication Flow

Authentik protects selected services via Traefik's forwardAuth middleware.

Authentik forward auth - the outpost intercepts requests and checks with the Authentik server before allowing access

Cross-Server Management

Portainer on the main VPS manages all three servers via agents over Tailscale.

Centralized management - Portainer controls all servers, Homepage provides the at-a-glance dashboard

Service Breakdown

Networking & Security

Traefik - Single entry point for all HTTP/HTTPS traffic. Handles TLS via Let's Encrypt, routes to local containers and remote servers via Tailscale IPs. Also routes Minecraft TCP traffic on :25565.
Authentik - Full SSO stack with server, worker, LDAP provider, and a forward auth outpost on the main VPS. Protects Jellyfin and Transmission via Traefik's forwardAuth middleware.
Technitium - DNS server accessible over Tailscale only (:53 bound to Tailscale IP). Logs to MariaDB.
Tailscale - Mesh VPN connecting all three servers. Traefik uses Tailscale IPs to reverse proxy services on remote VPSes.

Media Automation

Requests flow through a fully automated pipeline: Jellyseerr (request UI) -> Sonarr/Radarr (library managers) -> Prowlarr (indexer) -> Byparr (CAPTCHA solving) -> Transmission (downloads via Mullvad VPN) -> Unmanic (transcoding) -> Jellyfin (streaming). All media lives on the Hetzner Storage Box mounted across servers.

Email

Self-hosted Docker Mailserver handles SMTP/IMAP with SpamAssassin and Fail2ban. Roundcube provides webmail. Both ntfy and Kener route notifications through the mail server.

Everything Else

Linkwarden - Bookmark manager with its own Postgres and Meilisearch instances
PocketBase - Backend for side projects
ntfy - Push notifications (powers the /ping page on this site)
Kener - Status page at status.kanishksachdev.com
Homepage - Dashboard at home.kanishksachdev.com
Minecraft - Vanilla server, because why not
Portainer - Manages all three servers via remote agents
Cloud Commander - Web file manager for the storage box

Transmission VPS

Isolated server dedicated to torrenting. Gluetun wraps Transmission's traffic through a Mullvad WireGuard tunnel (Sweden exit). Traefik on the main VPS reverse proxies the web UI over Tailscale, protected by Authentik.

OCI VPS

Free-tier Oracle Cloud instance running an Unmanic worker node for distributed transcoding, mounting the shared storage box.
